#include <AttentionBank.h>

Public Member Functions
	AttentionBank (AtomTable &)

	~AttentionBank ()

void	shutdown (void)

AFCHSigl &	AddAFSignal ()

AFCHSigl &	RemoveAFSignal ()

long	getTotalSTI () const

long	getTotalLTI () const

long	getSTIFunds () const

long	getLTIFunds () const

long	updateSTIFunds (AttentionValue::sti_t diff)

long	updateLTIFunds (AttentionValue::lti_t diff)

AttentionValue::sti_t	getAttentionalFocusBoundary () const

AttentionValue::sti_t	setAttentionalFocusBoundary (AttentionValue::sti_t s)

AttentionValue::sti_t	getMaxSTI (bool average=true) const

AttentionValue::sti_t	getMinSTI (bool average=true) const

void	updateMinSTI (AttentionValue::sti_t m)

void	updateMaxSTI (AttentionValue::sti_t m)

float	getNormalisedSTI (AttentionValuePtr, bool average, bool clip) const

float	getNormalisedSTI (AttentionValuePtr) const

float	getNormalisedZeroToOneSTI (AttentionValuePtr, bool average, bool clip) const

Private Member Functions
void	AVChanged (Handle, AttentionValuePtr, AttentionValuePtr)

Private Attributes
boost::signals2::connection	AVChangedConnection

AttentionValue::sti_t	attentionalFocusBoundary

AFCHSigl	_AddAFSignal

AFCHSigl	_RemoveAFSignal

opencog::recent_val < AttentionValue::sti_t >	maxSTI

opencog::recent_val < AttentionValue::sti_t >	minSTI

std::mutex	lock_maxSTI

std::mutex	lock_minSTI

long	fundsSTI

long	fundsLTI

long	startingFundsSTI

long	startingFundsLTI

std::mutex	lock_funds

Detailed Description

Definition at line 47 of file AttentionBank.h.

Constructor & Destructor Documentation

AttentionBank::AttentionBank ( AtomTable & atab )

The table notifies us about AV changes

Definition at line 33 of file AttentionBank.cc.

References attentionalFocusBoundary, AVChanged(), AVChangedConnection, opencog::AtomTable::AVChangedSignal(), fundsLTI, fundsSTI, startingFundsLTI, and startingFundsSTI.

AttentionBank::~AttentionBank ( )

Definition at line 53 of file AttentionBank.cc.

Member Function Documentation

AFCHSigl& opencog::AttentionBank::AddAFSignal ( )

inline

Provide ability for others to find out about atoms that cross in or out of the AttentionalFocus

Definition at line 90 of file AttentionBank.h.

References _AddAFSignal.

Here is the caller graph for this function:

void AttentionBank::AVChanged	(	Handle	h,
		AttentionValuePtr	old_av,
		AttentionValuePtr	new_av
	)

private

Definition at line 56 of file AttentionBank.cc.

References AddAFSignal(), attentionalFocusBoundary, fundsSTI, RemoveAFSignal(), updateLTIFunds(), and updateSTIFunds().

Here is the caller graph for this function:

AttentionValue::sti_t AttentionBank::getAttentionalFocusBoundary ( ) const

Get attentional focus boundary, generally atoms below this threshold won't be accessed unless search methods are unsuccessful on those that are above this value.

Returns: Short Term Importance threshold value

Definition at line 153 of file AttentionBank.cc.

References attentionalFocusBoundary.

Here is the caller graph for this function:

long AttentionBank::getLTIFunds ( ) const

Get the LTI funds available in the AtomSpace pool.

Returns: LTI funds available

Definition at line 101 of file AttentionBank.cc.

References fundsLTI, and lock_funds.

Here is the caller graph for this function:

AttentionValue::sti_t AttentionBank::getMaxSTI ( bool average = true ) const

Get the maximum STI observed in the AtomSpace.

Parameters

average If true, return an exponentially decaying average of maximum STI, otherwise return the actual maximum.

Returns: Maximum STI

Definition at line 133 of file AttentionBank.cc.

References lock_maxSTI, and maxSTI.

Here is the caller graph for this function:

AttentionValue::sti_t AttentionBank::getMinSTI ( bool average = true ) const

Get the minimum STI observed in the AtomSpace.

Parameters

average If true, return an exponentially decaying average of minimum STI, otherwise return the actual maximum.

Returns: Minimum STI

Definition at line 143 of file AttentionBank.cc.

References lock_minSTI, and minSTI.

Here is the caller graph for this function:

float AttentionBank::getNormalisedSTI	(	AttentionValuePtr	av,
		bool	average,
		bool	clip
	)		const

Change the Very-Long-Term Importance of an attention value holder Retrieve the doubly normalised Short-Term Importance between -1..1 for a given AttentionValue. STI above and below threshold normalised separately and linearly.

Parameters

h	The attention value holder to get STI for
average	Should the recent average max/min STI be used, or the exact min/max?
clip	Should the returned value be clipped to -1..1? Outside this range can be return if average=true

Returns: normalised STI between -1..1

Definition at line 164 of file AttentionBank.cc.

References getAttentionalFocusBoundary(), getMaxSTI(), and getMinSTI().

Here is the caller graph for this function:

float AttentionBank::getNormalisedSTI ( AttentionValuePtr av ) const

See Also: getNormalisedSTI()

Definition at line 190 of file AttentionBank.cc.

References getAttentionalFocusBoundary(), getMaxSTI(), and getMinSTI().

float AttentionBank::getNormalisedZeroToOneSTI	(	AttentionValuePtr	av,
		bool	average,
		bool	clip
	)		const

Retrieve the linearly normalised Short-Term Importance between 0..1 for a given AttentionValue.

Parameters

h	The attention value holder to get STI for
average	Should the recent average max/min STI be used, or the exact min/max?
clip	Should the returned value be clipped to 0..1? Outside this range can be return if average=true

Returns: normalised STI between 0..1

Definition at line 199 of file AttentionBank.cc.

References getMaxSTI(), and getMinSTI().

Here is the caller graph for this function:

long AttentionBank::getSTIFunds ( ) const

Get the STI funds available in the AtomSpace pool.

Returns: STI funds available

Definition at line 95 of file AttentionBank.cc.

References fundsSTI, and lock_funds.

Here is the caller graph for this function:

long AttentionBank::getTotalLTI ( ) const

Get the total amount of LTI in the AtomSpace, sum of all LTI across atoms.

Returns: total LTI in AtomSpace

Definition at line 89 of file AttentionBank.cc.

References fundsLTI, lock_funds, and startingFundsLTI.

long AttentionBank::getTotalSTI ( ) const

Get the total amount of STI in the AtomSpace, sum of STI across all atoms.

Returns: total STI in AtomSpace

Definition at line 83 of file AttentionBank.cc.

References fundsSTI, lock_funds, and startingFundsSTI.

AFCHSigl& opencog::AttentionBank::RemoveAFSignal ( )

inline

Definition at line 91 of file AttentionBank.h.

References _RemoveAFSignal.

Here is the caller graph for this function:

AttentionValue::sti_t AttentionBank::setAttentionalFocusBoundary ( AttentionValue::sti_t s )

Change the attentional focus boundary. Some situations may benefit from less focussed searches.

Parameters

s	New threshold

Returns: Short Term Importance threshold value

Definition at line 158 of file AttentionBank.cc.

References attentionalFocusBoundary.

Here is the caller graph for this function:

void AttentionBank::shutdown ( void )

This must be called before the AtomTable is destroyed. Which means that it cannot be in the destructor (since the AtomTable is probably gone by then, leading to a crash. XXX FIXME yes this is a tacky hack to fix a design bug.

Definition at line 48 of file AttentionBank.cc.

References AVChangedConnection.

Here is the caller graph for this function:

long AttentionBank::updateLTIFunds ( AttentionValue::lti_t diff )

Definition at line 114 of file AttentionBank.cc.

References fundsLTI, and lock_funds.

Here is the caller graph for this function:

void AttentionBank::updateMaxSTI ( AttentionValue::sti_t m )

Update the maximum STI observed in the connected AtomSpace. Min/max are not updated on setSTI because average is calculate by lobe cycle, although this could potentially also be handled by the cogServer.

Warning: Should only be used by attention allocation system.

Parameters

m	New maximum STI

Definition at line 121 of file AttentionBank.cc.

References lock_maxSTI, and maxSTI.

Here is the caller graph for this function:

void AttentionBank::updateMinSTI ( AttentionValue::sti_t m )

Update the minimum STI observed in the connected AtomSpace. Min/max are not updated on setSTI because average is calculate by lobe cycle, although this could potentially also be handled by the cogServer.

Warning: Should only be used by attention allocation system.

Parameters

m	New minimum STI

Definition at line 127 of file AttentionBank.cc.

References lock_minSTI, and minSTI.

Here is the caller graph for this function:

long AttentionBank::updateSTIFunds ( AttentionValue::sti_t diff )

Definition at line 107 of file AttentionBank.cc.

References fundsSTI, and lock_funds.

Here is the caller graph for this function:

Member Data Documentation

AFCHSigl opencog::AttentionBank::_AddAFSignal

private

Signal emitted when an atom crosses in or out of the AttentionalFocus

Definition at line 61 of file AttentionBank.h.

AFCHSigl opencog::AttentionBank::_RemoveAFSignal

private

Definition at line 62 of file AttentionBank.h.

AttentionValue::sti_t opencog::AttentionBank::attentionalFocusBoundary

private

Boundary at which an atom is considered within the attentional focus of opencog. Atom's with STI less than this value are not charged STI rent

Definition at line 58 of file AttentionBank.h.

boost::signals2::connection opencog::AttentionBank::AVChangedConnection

private

The connection by which we are notified of AV changes

Definition at line 50 of file AttentionBank.h.

long opencog::AttentionBank::fundsLTI

private

Definition at line 73 of file AttentionBank.h.

long opencog::AttentionBank::fundsSTI

private

Definition at line 72 of file AttentionBank.h.

std::mutex opencog::AttentionBank::lock_funds

mutableprivate

Definition at line 78 of file AttentionBank.h.

std::mutex opencog::AttentionBank::lock_maxSTI

mutableprivate

Definition at line 67 of file AttentionBank.h.

std::mutex opencog::AttentionBank::lock_minSTI

mutableprivate

Definition at line 68 of file AttentionBank.h.

opencog::recent_val<AttentionValue::sti_t> opencog::AttentionBank::maxSTI

private

Definition at line 64 of file AttentionBank.h.

opencog::recent_val<AttentionValue::sti_t> opencog::AttentionBank::minSTI

private

Definition at line 65 of file AttentionBank.h.

long opencog::AttentionBank::startingFundsLTI

private

Definition at line 76 of file AttentionBank.h.

long opencog::AttentionBank::startingFundsSTI

private

Definition at line 75 of file AttentionBank.h.

The documentation for this class was generated from the following files:

opencog/atomspace/AttentionBank.h
opencog/atomspace/AttentionBank.cc
